PMI Integrity Analyzer by EQBAY Authorised Dealer – Advanced Filter Integrity Testing System

The Porous Materials Inc. Integrity Analyzer, available through EQBAY authorised dealer, is a high precision instrument designed for fully automated evaluation of filter integrity and pore structure characteristics. The system detects even minimal gas flow through wetted samples before reaching the bubble point, allowing accurate assessment of filter performance and reliability. Utilizing advanced pressure and flow control technology, the analyzer performs non destructive testing across a wide range of materials including membranes, filter media, and porous structures. It measures key parameters such as bubble point, gas permeability, and microflow behavior, providing critical insights for quality control and research applications. The system supports testing under various conditions including tension, compression, and elevated temperatures to simulate real operating environments. With a wide pore size range from 0.013 to 500 microns, pressure capability up to 500 psi, and high resolution measurement, the analyzer ensures precise, repeatable, and reliable results. Integrated software enables full automation, real time graphical data display, and report generation, making it a powerful solution for advanced filtration analysis across laboratory and industrial settings.

Key Features:

• Fully automated filter integrity and bubble point testing
• Non destructive testing for reliable sample evaluation
• Detects microflow before bubble point for high sensitivity
• Pore size measurement range from 0.013 to 500 microns
• Pressure range up to 500 psi
• Measures gas permeability including low flow samples
• Supports testing under tension, compression, and temperature conditions
• Real time graphical display of test data
• User friendly software for control, data acquisition, and reporting
• Wide sample compatibility for membranes, filters, and porous materials
